Inspyre Concorde v3 Bmx Pro Xl - Lime/Black

BMX INSPYRE CONCORDE V3

Custom BMX bikes are built with high-end components to deliver an ultra-performance bike.

SPECIFICATIONS

• Frame: Inspyre Concorde V3 - Pro XL
• Fork: Pride Apex Carbon Tapered - 20mm
• Handlebars: Pride Sevenmotion V2 - 7.5" - Ø22.2mm
• Grips: Sensus Lite
• Stem: Pride Cayman V2 54mm - Ø22.2mm
• Headset: Forward Tapered Integrated 45x45°
• Brake Kit: Shimano XT M8100
• Brake Disc: Forward Gen - 120mm
• Rims: Pride Helium Pro 24-406
• Front Hub: Onyx Helix - 20mm
• Rear Hub: Onyx Ultra SS - 10mm
• Tires: Schwalbe SX-R Perf - 20x1.85"
• Bottom Bracket: Pride BB86 Interlock
• Crankset: Beringer E2 - 175mm
• Chainring: Rennen - 43.2T
• Cog: Pride Matrix Alu - 16T
• Chain: Kmc X9
• Saddle: Pride Control Pivotal
• Seatpost: Pride Spline AL - Ø31.6mm
• Seat Clamp: Forward Elite - 34.9mm

• Weight: 8.26kg

GEOMETRY - FRAME

• Top Tube: 21.25" / 540mm
• Rider Area: 575mm
• Rear Chainstay Length (min): 14.4" / 365mm
• Rear Chainstay Length (max): 15.4" / 390mm
• Head Angle: 74°
• Seat Tube Angle: 72°
• Bottom Bracket Height: 45.4mm
